Basic Information

• Year: 2026
• Make: Yamaha
• Model: Raptor
• Trim: 700R SE
• Stock Number: 117378
• VIN: 5Y4AML6E3TA117378
• Condition: New
• Type: Sport
• Mileage: 1
• Primary Color: WHITE

Chassis / Suspension

• Frame: Aluminum / Steel
• Front Adjustable Fork Pre-Load
• Front Adjustable Rebound Damping
• Front Travel (in): 9.1
• Front Travel (mm): 231.1
• Number Rear Shock Absorbers: 1
• Rear Adjustable Rebound Damping
• Rear Adjustable Shock / Spring Pre-Load
• Rear Suspension Material: Aluminum
• Rear Travel (in): 10.1
• Rear Travel (mm): 256.5
• Steering Control: Handlebar
• Steering Type: Manual
• Suspension – Front: Independent Double Wishbone
• Suspension – Rear: Swing Arm

Comfort

• Adjustable Levers
• Seat Location: Driver
• Seat Material: Vinyl
• Seat Type: One-Piece

Drivetrain

• Transmission Type: Manual
• Driveline Type: 4X2
• Number Of Driveline Modes: 1
• Rear Solid Axle
• Number Of Speeds: 5
• Primary Drive (Rear Wheel): Chain
• Reverse

Engine

• Bore (in): 4.02
• Bore (mm): 102
• Carburetion Type: Fuel Injected
• Compression Ratio: 10.0:1
• Cylinders: 1
• Displacement (ci): 41.9
• Engine Cooling: Liquid
• Engine Size (cc): 686
• Engine Stroke: 4-Stroke
• Fuel Capacity (gal): 2.9
• Fuel Injector
• Fuel Injector Size (mm): 44
• Fuel Requirements: Regular
• Starter Type: Electric
• Stroke (in): 3.31
• Stroke (mm): 84
• Valve Configuration: SOHC
• Valves: 4
• Valves Per Cylinder: 4

Other Information

• Brush Guard

Safety

• Brakes – Front: Dual Hydraulic Disc
• Brakes – Rear: Hydraulic Disc
• Halogen Headlight(s)
• Headlight(s)

Specifications

• Bash Plate (Front)
• Body Material: Plastic
• Front Tire Diameter (in): 22
• Front Tire Width: 7
• Ground Clearance (in): 9.5
• Ground Clearance (mm): 241.3
• Height (Inches): 43
• Height (mm): 1115.1
• Length (Inches): 72
• Length (mm): 1844
• Rear Tire Diameter (in): 20
• Rear Tire Width: 10
• Tube / Tubeless: Tubeless
• Wet Weight (kg): 191.4
• Wet Weight (lbs): 422
• Wheelbase (in): 50.4
• Wheelbase (mm): 1280.2
• Wheels Composition: Aluminum
• Width (Inches): 45
• Width (mm): 1155.7
