Basic Information

• Year: 2026
• Make: Polaris
• Model: Sportsman 570
• Trim: Trail
• Stock Number: 104976
• VIN: 4XASHY571TA104976
• Condition: New
• Type: Utility
• Mileage: 1
• Primary Color: RED

Chassis / Suspension

• Frame: Steel
• Front Rack Capacity (lbs): 90
• Front Travel (in): 8.9
• Front Travel (mm): 226
• Number Rear Shock Absorbers: 2
• Rear Adjustable Shock / Spring Pre-Load
• Rear Suspension Material: Steel
• Rear Travel (in): 9.5
• Rear Travel (mm): 241
• Steering Control: Handlebar
• Steering Type: Power
• Suspension – Front: Independent Double A-Arm
• Suspension – Rear: Independent Double A-Arm

Comfort

• Clock
• Digital Instrumentation
• Hour Meter
• Seat Location: Driver
• Seat Material: Vinyl
• Seat Type: One-Piece

Drivetrain

• Transmission Type: Continuously Variable (CVT)
• Engine Braking System
• Differential Lock
• Differential Lock Location: Rear
• Driveline Brand: On-Demand
• Driveline Type: Selectable 4X2 / 4X4
• Number Of Driveline Modes: 2
• Hi / Low Range
• Primary Drive (Front Wheel): Shaft
• Primary Drive (Rear Wheel): Shaft
• Reverse
• Transmission Brand: Polaris Variable Transmission (PVT)
• Limited Slip Differential
• Limited Slip Differential Location: Rear
• Primary Drive (Engine / Transmission): Belt

Engine

• Bore (in): 3.9
• Bore (mm): 99
• Carburetion Type: Fuel Injected
• Compression Ratio: 10:1
• Cylinders: 1
• Displacement (ci): 34.6
• Engine Brand Name: ProStar
• Engine Cooling: Liquid
• Engine Size (cc): 567
• Engine Stroke: 4-Stroke
• Fuel Capacity (gal): 4.5
• Fuel Injector
• Fuel Requirements: Regular
• Horsepower (kW): 32.8
• Starter Type: Electric
• Stroke (in): 2.9
• Stroke (mm): 73.6
• Valve Configuration: DOHC
• Valves: 4
• Valves Per Cylinder: 4

Other Information

• Front Fender Flairs
• Rear Fender Flairs
• Rack Rails
• Power Outlet
• Plow Mount
• Brush Guard

Safety

• Brakes – Front: Hydraulic Disc
• Brakes – Rear: Hydraulic Disc
• Roller Fairlead
• Headlight(s)

Specifications

• A-Arm Skid Plate (Front)
• A-Arm Skid Plate (Rear)
• Bash Plate (Front)
• Body Material: Composite
• Dry Weight (lbs): 847
• Dry Weight (kg): 384
• Front Rack Capacity (kgs): 40.8
• Front Tire Diameter (in): 26
• Front Tire Width: 8
• Ground Clearance (in): 11.5
• Ground Clearance (mm): 290
• Height (Inches): 47
• Height (mm): 1194
• Length (Inches): 83
• Length (mm): 2108
• Payload Capacity (kgs): 220
• Rear Hitch
• Rear Tire Diameter (in): 26
• Rear Tire Width: 10
• Towing Capacity (kgs): 612
• Towing Capacity (lbs): 1350
• Wet Weight (kg): 402
• Wet Weight (lbs): 886
• Wheelbase (in): 50.5
• Wheelbase (mm): 1283
• Wheels Composition: Aluminum
• Width (Inches): 48
• Width (mm): 1219
• Winch
• Winch Brand Name: Polaris
• Winch Weight (kgs): 1588
• Winch Weight (lbs): 3500
