Basic Information

• Year: 2026
• Make: Polaris
• Model: Ranger XP 1000
• Trim: Premium Blue Labyrinth
• Stock Number: 029904
• VIN: 4XARRE99XT8029904
• Condition: New
• Type: Utility
• Mileage: 1
• Primary Color: BLUE

Chassis / Suspension

• Frame: Steel
• Front Adjustable Fork Pre-Load
• Front Stabilizer Bar
• Front Travel (in): 10
• Front Travel (mm): 254
• Number Rear Shock Absorbers: 2
• Rear Adjustable Shock / Spring Pre-Load
• Rear Suspension Material: Steel
• Rear Travel (in): 10
• Rear Travel (mm): 254
• Steering Control: Steering Wheel
• Steering Type: Power
• Suspension – Front: Independent Double A-Arm
• Suspension – Rear: Independent Double A-Arm

Comfort

• Clock
• Digital Instrumentation
• Seat Material: Vinyl
• Seat Type: Bucket

Drivetrain

• Transmission Type: Continuously Variable (CVT)
• Driveline Brand: On-Demand
• Driveline Type: Selectable 4X2 / AWD
• Number Of Driveline Modes: 3
• Hi / Low Range
• Primary Drive (Front Wheel): Shaft
• Primary Drive (Rear Wheel): Shaft
• Reverse
• Transmission Brand: Polaris Variable Transmission (PVT)
• Limited Slip Differential
• Limited Slip Differential Location: Center
• Primary Drive (Engine / Transmission): Belt

Engine

• Bore (in): 3.66
• Bore (mm): 93
• Carburetion Type: Fuel Injected
• Compression Ratio: 10.8:1
• Cylinders: 2
• Displacement (ci): 60.9
• Engine Brand Name: ProStar
• Engine Cooling: Liquid
• Engine Size (cc): 999
• Engine Stroke: 4-Stroke
• Fuel Capacity (gal): 11.5
• Fuel Injector
• Fuel Requirements: Regular
• Horsepower (kW): 61.2
• Starter Type: Electric
• Stroke (in): 2.89
• Stroke (mm): 73.6
• Torque (Ft Lbs): 62
• Torque (Nm): 84.1
• Valve Configuration: DOHC
• Valves: 8
• Valves Per Cylinder: 4
• Engine Immobilizer

Other Information

• Cab Cage
• Cab Canopy
• Cab Canopy Material: Hard
• Cab Doors
• Cab Doors Material: Soft
• Cab Rollbar
• Cargo Bed Integral Tie-Down Hooks
• Power Outlet
• Brush Guard

Safety

• Brakes – Front: Hydraulic Disc
• Brakes – Rear: Hydraulic Disc
• Seat Belts
• Headlight(s)

Specifications

• A-Arm Skid Plate (Front)
• A-Arm Skid Plate (Rear)
• Bash Plate (Front)
• Bed Capacity (kgs.): 454
• Bed Capacity (lbs.): 1000
• Body Material: Plastic
• Cargo Bed Bed Height (in): 12.5
• Cargo Bed Bed Height (mm): 320
• Cargo Bed Bed Length (in): 36.75
• Cargo Bed Bed Length (mm): 930
• Cargo Bed Bed Width (in): 54.25
• Cargo Bed Bed Width (mm): 1380
• Cargo Bed Material: Polyethylene
• Cargo Bed Tilt
• Dry Weight (lbs): 1693
• Dry Weight (kg): 768
• Front Tire Diameter (in): 29
• Front Tire Width: 9
• Full Length Skid Plate
• Ground Clearance (in): 14
• Ground Clearance (mm): 360
• GVWR (kgs): 1633
• GVWR (lbs): 3600
• Height (Inches): 79
• Height (mm): 2010
• Length (Inches): 120
• Length (mm): 3050
• Payload Capacity (kgs): 680
• Rear Hitch
• Rear Tire Diameter (in): 29
• Rear Tire Width: 11
• Towing Capacity (kgs): 1134
• Towing Capacity (lbs): 2500
• Turning Radius (ft): 13
• Wheelbase (in): 81
• Wheelbase (mm): 2060
• Wheels Composition: Aluminum
• Width (Inches): 62
• Width (mm): 1580
