Basic Information

• Year: 2026
• Make: Honda
• Model: FourTrax Recon
• Trim: ES
• Stock Number: 202566
• VIN: 1HFTE5403TJ202566
• Condition: New
• Type: Utility
• Mileage: 1
• Primary Color: RED

Chassis / Suspension

• Frame: Steel
• Front Rack Capacity (lbs): 33
• Front Travel (in): 5.1
• Front Travel (mm): 129.5
• Number Rear Shock Absorbers: 1
• Rear Suspension Material: Steel
• Rear Travel (in): 4.9
• Rear Travel (mm): 124.5
• Steering Control: Handlebar
• Steering Type: Manual
• Suspension – Front: Independent Double Wishbone
• Suspension – Rear: Swing Arm

Comfort

• Seat Location: Driver
• Seat Material: Vinyl
• Seat Type: One-Piece

Drivetrain

• Transmission Type: Manual / Automatic Clutch
• Engine Braking System
• Driveline Type: 4X2
• Number Of Driveline Modes: 1
• Number Of Speeds: 5
• Primary Drive (Rear Wheel): Shaft
• Reverse

Engine

• Bore (in): 2.7
• Bore (mm): 68.5
• Carburetion Type: Carburetor
• Carburetor
• Compression Ratio: 9.2:1
• Cylinders: 1
• Displacement (ci): 14
• Engine Cooling: Air
• Engine Size (cc): 229
• Engine Stroke: 4-Stroke
• Fuel Capacity (gal): 2.4
• Fuel Capacity Reserve (gal): 0.6
• Fuel Capacity Reserve (l): 2.3
• Fuel Requirements: Regular
• Number Of Carburetors: 1
• Snorkel Air Intake
• Starter Type: Electric / Pull
• Stroke (in): 2.45
• Stroke (mm): 62.2
• Valve Configuration: OHV
• Valves: 2
• Valves Per Cylinder: 2

Other Information

• Fender Storage
• Front Fender Flairs
• Rear Fender Flairs
• Power Outlet
• Brush Guard

Safety

• Brakes – Front: Dual Sealed Hydraulic Drum
• Brakes – Rear: Sealed Drum
• Front Brake Diameter (in): 5.1
• Front Brake Diameter (mm): 130
• Rear Brake Diameter (in): 5.5
• Rear Brake Diameter (mm): 140
• Halogen Headlight(s)
• Headlight(s)

Specifications

• Bash Plate (Front)
• Front Rack Capacity (kgs): 15
• Front Tire Diameter (in): 22
• Front Tire Width: 7
• Ground Clearance (in): 6
• Ground Clearance (mm): 152.4
• GVWR (kgs): 370.1
• GVWR (lbs): 816
• Height (Inches): 42
• Height (mm): 1069.3
• Length (Inches): 75
• Length (mm): 1905
• Rear Tire Diameter (in): 22
• Rear Tire Width: 10
• Towing Capacity (kgs): 226.8
• Towing Capacity (lbs): 500
• Turning Radius (ft): 8.5
• Wet Weight (kg): 201
• Wet Weight (lbs): 443
• Wheelbase (in): 44.5
• Wheelbase (mm): 1130.3
• Wheels Composition: Steel
• Width (Inches): 40
• Width (mm): 1033.8
