Basic Information

• Year: 2026
• Make: Honda
• Model: FourTrax Foreman
• Trim: 4X4 Truetimber Atera Camo
• Stock Number: 202689
• VIN: 1HFTE4405TJ202689
• Condition: New
• Type: Utility
• Mileage: 1
• Primary Color: RED

Chassis / Suspension

• Frame: Steel
• Front Adjustable Fork Pre-Load
• Front Rack Capacity (lbs): 88
• Front Travel (in): 7.3
• Front Travel (mm): 185
• Number Rear Shock Absorbers: 1
• Rear Adjustable Shock / Spring Pre-Load
• Rear Suspension Material: Steel
• Rear Travel (in): 7.3
• Rear Travel (mm): 185
• Steering Control: Handlebar
• Steering Type: Manual
• Suspension – Front: Independent Double Wishbone
• Suspension – Rear: Swing Arm

Comfort

• Clock
• Digital Instrumentation
• Hour Meter
• Seat Location: Driver
• Seat Material: Vinyl
• Seat Type: One-Piece

Drivetrain

• Transmission Type: Manual / Automatic Clutch
• Engine Braking System
• Driveline Brand: TraxLok
• Driveline Type: Selectable 4X2 / 4X4
• Number Of Driveline Modes: 3
• Number Of Speeds: 5
• Primary Drive (Front Wheel): Shaft
• Primary Drive (Rear Wheel): Shaft
• Reverse
• Limited Slip Differential
• Limited Slip Differential Location: Front
• Primary Drive (Engine / Transmission): Gear

Engine

• Bore (in): 3.78
• Bore (mm): 96
• Carburetion Type: Fuel Injected
• Compression Ratio: 9.5:1
• Cylinders: 1
• Displacement (ci): 31.6
• Engine Cooling: Liquid
• Engine Size (cc): 518
• Engine Stroke: 4-Stroke
• Fuel Capacity (gal): 3.9
• Fuel Capacity Reserve (gal): 1.3
• Fuel Capacity Reserve (l): 4.9
• Fuel Injector
• Fuel Injector Size (mm): 36
• Snorkel Air Intake
• Starter Type: Electric
• Stroke (in): 2.82
• Stroke (mm): 71.5
• Valve Configuration: OHV
• Valves: 2
• Valves Per Cylinder: 2

Other Information

• Fender Storage
• Front Fender Flairs
• Rear Fender Flairs
• Power Outlet
• CV Boot Cover
• Brush Guard

Safety

• Brakes – Front: Dual Hydraulic Disc
• Brakes – Rear: Sealed Drum
• Front Brake Diameter (in): 7.5
• Front Brake Diameter (mm): 190
• Rear Brake Diameter (in): 6.3
• Rear Brake Diameter (mm): 160
• Halogen Headlight(s)
• Headlight(s)

Specifications

• Bash Plate (Front)
• Front Rack Capacity (kgs): 39.9
• Front Tire Diameter (in): 25
• Front Tire Width: 8
• Full Length Skid Plate
• Ground Clearance (in): 7.5
• Ground Clearance (mm): 190.5
• Height (Inches): 47
• Height (mm): 1214
• Length (Inches): 82
• Length (mm): 2105.7
• Rear Hitch
• Rear Tire Diameter (in): 25
• Rear Tire Width: 10
• Towing Capacity (kgs): 384.7
• Towing Capacity (lbs): 848
• Turning Radius (ft): 10.5
• Wet Weight (kg): 288
• Wet Weight (lbs): 635
• Wheelbase (in): 50
• Wheelbase (mm): 1270
• Wheels Composition: Steel
• Width (Inches): 47
• Width (mm): 1204
