Basic Information

• Year: 2026
• Make: CFMOTO
• Model: UFORCE
• Trim: 800 XL
• Stock Number: 002234
• VIN: LCELVYZU5T6002234
• Condition: New
• Type: Utility
• Mileage: 1
• Primary Color: BLUE

Chassis / Suspension

• Frame: Steel
• Front Adjustable Fork Pre-Load
• Front Travel (in): 8.9
• Front Travel (mm): 226.1
• Number Rear Shock Absorbers: 2
• Rear Adjustable Shock / Spring Pre-Load
• Rear Stabilizer Bar
• Rear Suspension Material: Steel
• Rear Travel (in): 8.9
• Rear Travel (mm): 226.1
• Steering Control: Steering Wheel
• Steering Type: Power
• Suspension – Front: Independent A-Arm
• Suspension – Rear: Independent Double A-Arm

Comfort

• Clock
• Digital Instrumentation
• Hour Meter
• Seat Material: Vinyl
• Seat Type: Bench

Drivetrain

• Transmission Type: Continuously Variable (CVT)
• Engine Braking System
• Differential Lock
• Differential Lock Location: Rear
• Driveline Type: Selectable 4X2 / 4X4
• Number Of Driveline Modes: 2
• Hi / Low Range
• Primary Drive (Front Wheel): Shaft
• Primary Drive (Rear Wheel): Shaft
• Reverse
• Transmission Brand: CVTech
• Primary Drive (Engine / Transmission): Chain

Engine

• Carburetion Brand: Bosch
• Carburetion Type: Fuel Injected
• Cylinders: 2
• Displacement (ci): 48.8
• Engine Cooling: Liquid
• Engine Size (cc): 800
• Engine Stroke: 4-Stroke
• Fuel Capacity (gal): 10.5
• Fuel Injector
• Fuel Requirements: Regular
• Horsepower (kW): 47
• Horsepower RPM: 7000
• Starter Type: Electric
• Torque (Ft Lbs): 51
• Torque (Nm): 69.1
• Torque RPM: 5500
• Valve Configuration: SOHC
• Valves: 8
• Valves Per Cylinder: 4

Other Information

• Cab / Bed Divider
• Cab Cage
• Cab Canopy
• Cab Canopy Material: Hard
• Cab Doors
• Cab Doors Material: Soft
• Cab Rollbar
• Cargo Bed Integral Tie-Down Hooks
• Front Fender Flairs
• Rear Fender Flairs
• Power Outlet

Safety

• Brakes – Front: Hydraulic Disc
• Brakes – Rear: Hydraulic Disc
• Roller Fairlead
• Seat Belts
• Headlight(s)

Specifications

• A-Arm Skid Plate (Front)
• A-Arm Skid Plate (Rear)
• Bash Plate (Front)
• Bash Plate (Rear)
• Bed Capacity (kgs.): 299.4
• Bed Capacity (lbs.): 660
• Body Material: Plastic
• Cargo Bed Tilt
• Dry Weight (lbs): 1629
• Dry Weight (kg): 738.9
• Front Tire Diameter (in): 27
• Front Tire Width: 9
• Full Length Skid Plate
• Ground Clearance (in): 11.8
• Ground Clearance (mm): 299.7
• Height (Inches): 79
• Height (mm): 2006.6
• Length (Inches): 143
• Length (mm): 3632.2
• Rear Hitch
• Rear Tire Diameter (in): 27
• Rear Tire Width: 11
• Towing Capacity (kgs): 680.4
• Towing Capacity (lbs): 1500
• Turning Radius (ft): 18
• Wheelbase (in): 109.1
• Wheelbase (mm): 2771.1
• Wheels Composition: Aluminum
• Width (Inches): 60
• Width (mm): 1524
• Winch
• Winch Weight (kgs): 2041.2
• Winch Weight (lbs): 4500
